Mobile UVSS Under Vehicle Scanner System Car Explosive UVSS Detector
Regular price ₦15,360,000.00
QUESTIONS & ANSWERS
Have a Question?
Be the first to ask a question about this.
Under Vehicle Surveillance System (UVSS)
High-Definition Vehicle Undercarriage Security Inspection System
The UVSS delivers advanced undercarriage scanning technology for comprehensive security screening at checkpoints, border crossings, and high-security facilities.
Key Security Features:
- Detects hidden threats and contraband with 5000×2048 pixel resolution
- Identifies objects as small as 2mm in diameter
- Supports vehicle speeds up to 30km/h with ALPR (70km/h without)
- Optional automatic license plate recognition integration
- Multi-scene monitoring with complete recording capabilities
Technical Specifications:
- 170° field of view covering width up to 4 meters
- Rugged IP68 waterproof rating for all-weather operation
- 20-ton weight capacity for all vehicle classes
- Operating temperature range: -10°C to 55°C
- Compact scanning unit: 450×400×88mm, 24kg
System Components:
- Grantech UFO6377H-SP1-953 processing unit with Intel Core 2 Duo
- 2GB memory (upgradable to 4GB)
- 500GB SATA2 hard disk
- Dual LAN with Intel Gigabit support
- 22" LCD monitor (1920×1080 resolution)
- Multiple language interface options
Integration Capabilities:
- Expandable for multi-device network deployment
- Compatible with barriers, gates and access control systems
- RS232/RS422 communication interfaces
