BAS-5030XBS-A X-Ray Security Screening Machine – High-Performance Baggage Inspection System
Regular price ₦8,800,000.00
QUESTIONS & ANSWERS
Have a Question?
Be the first to ask a question about this.
🔒 BAS-5030XBS-A X-Ray Security Screening Machine – High-Performance Baggage Inspection System
Model: BAS-5030XBS-A
Brand: BASEC AFRICA
✅ Product Overview:
The BAS-5030XBS-A X-Ray Security Screening System is a compact, high-performance inspection machine designed for rapid and precise detection of concealed threats in luggage, parcels, and packages. Widely used across airports, railway stations, embassies, government facilities, logistics centers, hotels, shopping malls, post offices, and other high-security areas, this machine is engineered to meet international standards with exceptional image quality and strong penetration capabilities.
Ideal for both indoor and semi-outdoor use, the BAS5030 integrates advanced detection technologies, an intuitive interface, and durable imported components to ensure long-term reliability and operator-friendly experience.
⚙️ Working Principle:
Using conveyor-driven scanning, the baggage is moved through the X-ray inspection tunnel. Upon detecting the item, sensors activate the X-ray source. The fan-shaped X-ray beam penetrates the item, and the resulting signal is captured by dual-energy semiconductor detectors. These signals are amplified and processed to create a detailed, high-resolution image displayed in real time, allowing for the rapid identification of dangerous or prohibited items.
🧩 Model Characteristics & Configuration:
-
Imported Components for durability and precision
-
Clear Image Output with high-resolution imaging system
-
Strong Penetrating Power for steel and dense materials
-
Low Radiation Leakage for safe operation
-
Long Service Life suitable for continuous use in busy environments
-
Compliant with latest international standards
🖥️ Specifications:
| Feature | Details |
|---|---|
| Display | 19-inch (or larger) industrial-grade monitor |
| X-Ray Source | USA-imported tube |
| Detector | Japanese Binson detector |
| Drum | German Yintono linear drum |
| Belt | Low-noise, green industrial belt |
| Color Modes | Color / Black & White / Inverse B&W |
| Image Resolution | 1024 × 1280 pixels |
| Image Grey Level | 4096 levels |
| Wire Resolution | 0.0787mm metal line |
| Penetration Resolution | 0.202mm copper wire under 3-step wedge |
| Steel Penetration | 8–12mm |
| Film Safety | ASA/ISO1600 compatible |
| X-ray Dose per Inspection | 1.5–3µGy |
| Max Leakage Radiation | <0.1µGy/h |
| Tunnel Size | 500mm (W) × 300mm (H) |
| Conveyor Speed | 0.2–0.22 m/s |
| Max Conveyor Load | 100–150kg |
| Processing System | Industrial-grade DSP embedded processor |
| Operation Interface | Soft-touch floating keyboard |
| Toolbox | Special toolbox included |
| Accessories | Button keyboard and mouse |
🛡️ Applications:
-
Airport Security Checkpoints
-
Railway and Bus Stations
-
Government Buildings
-
Embassies and Consulates
-
Conference and Exhibition Centers
-
Hotels and Malls
-
Logistics & Parcel Inspection
-
Educational Institutions
-
Industrial Security Operations
🔧 Why Choose the BAS5030?
-
Fast and Accurate Scanning
-
Imported Quality Components
-
User-Friendly Controls
-
Comprehensive Safety Compliance
-
Built to Perform in Demanding Environments
